Angular Contact Bearing
Class
P4 / P2
Origin
DE / SE
Standard
DIN 620
Lead
3-7 Days
Angular Contact Bearing
In Stock
Double Row Angular Contact Ball Bearing 3209B TVH C3 FAG for High-Precision CNC Machine Tools
ISO 9001 · DIN Certified
<p>Ensure your high-precision CNC machine tools maintain peak performance with the <strong>FAG 3209B TVH C3</strong> double row angular contact ball bearing, engineered to deliver stable long-term precision in critical machining operations. This bearing minimizes vibration and ensures consistent rotational accuracy, reducing downtime and enhancing the quality of your finished components.</p><ul><li>Featuring a polyamide (TVH) cage for low friction and high-speed capability, ideal for continuous-duty CNC applications</li><li>Complies with DIN 628-3 and ISO 15:2017 standards, ensuring seamless integration with your existing precision systems</li><li>Open design with C3 clearance provides optimal heat dissipation, maintaining performance even under heavy loads</li></ul><p>As an official FAG distributor, we handle all documentation and logistics coordination, so you can focus on your production schedule without unnecessary supplier management delays.</p>
Technical Specifications
- Type
- Angular Contact Bearing
- Precision Class
- P4 / P2
- Certification
- ISO 9001
- Radial Runout
- ≤ 1.5 μm
- Delivery
- 3-7 Business Days
Related Keywords
Reply within 12 hours
NDA available
Full certification docs
Precision packaging
Product Description
Technical Details & Application
Product Specifications
| Parameter | Details |
|---|---|
| Model NO. | Double Row Angular Contact Ball Bearing |
| Separated | Separated |
| Rows Number | Double |
| Material | Bearing Steel |
| Standard | DIN 628-3, ISO 15:2017 |
| Series | 32 Series, 33 Series (32bd, 33bd, 32da, 33da) |
| Cage | Polyamide (Tvh), Sheet Steel, Brass (MP) Cage |
| Seal Type | Open, 2z, 2hrs |
| Precision | P0 /P6 /P5 |
| Transport Package | Carton Pallet |
| Trademark | FAG |
| Origin | Jiangsu China |
| HS Code | 8482800000 |
Application Industries
| Industry | Typical Equipment |
|---|---|
| Manufacturing | High-Precision CNC Machine Tools, Spindles, Gearboxes |
Stop CNC Downtime with FAG 3209B TVH C3 Double Row Angular Contact Ball Bearing
CNC machine tool operators know the cost of unexpected spindle failure—hours of production loss, missed deadlines, and costly repairs. Many face the frustration of sourcing genuine high-precision bearings that meet strict DIN standards, only to wait weeks for delivery or receive inconsistent quality from unauthorized suppliers.
Genuine FAG 3209B TVH C3 Bearings in Stock for Immediate Shipment
As an official FAG distributor, we stock the FAG 3209B TVH C3 double row angular contact ball bearing—engineered for the high-rigidity requirements of CNC machine tool spindles. Our ISO 9001 compliant inspection system ensures each bearing meets DIN 628-3 standards, with P5 precision class available to minimize runout and vibration during high-speed operation.
Engineered for High-Precision CNC Machine Tool Performance
This double row angular contact ball bearing excels in applications requiring simultaneous radial and axial load handling, such as horizontal machining centers and precision lathes. The polyamide (TVH) cage provides stable ball guidance at speeds up to the bearing’s reference limit, reducing friction and heat buildup during extended production runs.
Key Technical Features for CNC Spindle Reliability
The FAG 3209B TVH C3 incorporates critical design elements for precision performance. Its double row configuration delivers 20% higher radial load capacity compared to single row designs, while the C3 clearance grade allows for thermal expansion in high-speed operation without preload loss. The open seal type minimizes rotational resistance, making it ideal for oil-lubricated spindle systems where maximum speed is prioritized. Manufactured from high-grade bearing steel, this bearing maintains dimensional stability even under the temperature fluctuations common in CNC machining environments.
Why Authentic FAG Bearings Reduce Total Cost of Ownership
Counterfeit bearings often fail prematurely due to substandard materials and poor manufacturing tolerances, leading to unplanned downtime that costs far more than the initial savings. Genuine FAG bearings like the 3209B TVH C3 undergo rigorous testing to ensure consistent performance, typically delivering 3-5 times longer service life in CNC applications. Our precision testing procedures, compliant with DIN standards, verify each bearing’s geometry and load capacity before shipment, eliminating the risk of installing non-conforming components in critical machinery.
Your Trusted Partner for High-Precision Bearing Solutions
With dual European brand official authorization for FAG and SKF, we provide complete traceability for every bearing—including full certification documents and export paperwork required for large-scale engineering projects. Our senior application engineers offer free technical consultation to ensure proper bearing selection, while our centralized warehouse in China (Shandong) Pilot Free Trade Zone maintains sufficient P4/P2 grade stock for urgent orders. Serving over 800 clients across 45+ countries, we specialize in premium shockproof logistics that protect precision components during transportation.
Packaging & Shipping
- Original FAG packaging with product certification and batch traceability documentation
- Secure carton pallet packaging to prevent damage during transit
- Express delivery options available for urgent maintenance needs
- Full logistics tracking provided from warehouse to delivery
- Minimum order quantity of 1 piece supported for emergency repairs
Get Your FAG 3209B TVH C3 Bearing Shipped Today
Don’t let bearing issues halt your CNC production. Send us your exact bearing requirements, including quantity and application details, and our team will provide a unified quotation within one working day. With our in-stock inventory, you can have the FAG 3209B TVH C3 bearing delivered quickly to minimize downtime and keep your machine tools operating at peak precision.
Frequently Asked Questions
Q: Are these genuine FAG bearings?
A: Yes, we are an official authorized FAG distributor. Every bearing comes with complete traceability documentation to verify authenticity, including authorization certificates from FAG.
Q: How do I confirm if the 3209B TVH C3 is suitable for my CNC machine?
A: Provide your machine model, spindle speed, and operating load conditions. Our senior application engineers will verify compatibility and recommend the optimal bearing configuration.
Q: What is your warranty policy?
A: We stand behind the quality of all genuine FAG products. Manufacturing defects are covered under FAG’s原厂质保标准, with unconditional replacement for non-conforming bearings.
Q: What is the minimum order quantity?
A: We accept orders for 1 piece, supporting both emergency maintenance and small-batch procurement needs.
Q: How long does shipping take?
A: In-stock bearings are shipped within 3-7 working days. We offer DHL, FedEx, UPS, air, and sea freight options to match your delivery timeline requirements.
Q: How can I verify the bearing’s authenticity upon receipt?
A: Check for FAG’s official packaging, laser-etched part numbers, and unique serial codes. We provide complete certification documents that can be cross-verified through FAG’s official channels.
Ready to order or need a quote?
Send your bearing designation, application details, and quantity — we’ll respond within 24 hours.
